1–9 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Set-output Values for Unselected Valves (During Profile)
FCC09 N43:5 Output #1
FCC10 N43:6 Output #2
FCC11 N43:7 Output #3
FCC12 N43:8 Output #4
FCC13 N43:9 Output #5
FCC14 N43:10 Output #6
FCC15 N43:11 Output #7
FCC16 N43:12 Output #8
Acceleration Ramp Rates
FCC17 N43:13 Output #1
FCC18 N43:14 Output #2
FCC19 N43:15 Output #3
FCC20 N43:16 Output #4
FCC21 N43:17 Output #5
FCC22 N43:18 Output #6
FCC23 N43:19 Output #7
FCC24 N43:20 Output #8
Deceleration Ramp Rates
FCC25 N43:21 Output #1
FCC26 N43:22 Output #2
FCC27 N43:23 Output #3
FCC28 N43:24 Output #4
FCC29 N43:25 Output #5
FCC30 N43:26 Output #6
FCC31 N43:27 Output #7
FCC32 N43:28 Output #8
End of Profile Set-output Values
FCC33 N43:29 Output #1
FCC34 N43:30 Output #2
FCC35 N43:31 Output #3
FCC36 N43:32 Output #4
FCC37 N43:33 Output #5
FCC38 N43:34 Output #6
FCC39 N43:35 Output #7
FCC40 N43:36 Output #8
Pressure Control Limits
FCC41 N43:37 Minimum limit
FCC42 N43:38 Maximum limit
FCC43 N43:39 % output for minimum
FCC44 N43:40 % output for maximum
Velocity Control Limits
FCC45 N43:41 Minimum limit
FCC46 N43:42 Maximum limit
FCC47 N43:43 % output for minimum
FCC48 N43:44 % output for maximum
