4–17 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 7
0813 CPC13 must be 00000 when CPC11 = 00000.
0814 CPC14 must be 00000 when CPC11 = 00000.
0815 CPC15 must be 00000 when CPC14 = 00000.
0816 CPC16 must be 00000 when CPC14 = 00000.
0817 CPC17 must be 00000 when CPC14 = 00000.
0821 CPC21 must be 00000 when CPC20 = 00000.
0822 CPC22 must be 00000 when CPC20 = 00000.
0823 CPC23 must be 00000 when CPC20 = 00000.
0824 CPC24 must be 00000 when CPC23 = 00000.
0825 CPC25 must be 00000 when CPC23 = 00000.
0826 CPC26 must be 00000 when CPC23 = 00000.
0830 CPC30 must be 00000 when CPC29 = 00000.
0831 CPC31 must be 00000 when CPC29 = 00000.
0832 CPC32 must be 00000 when CPC29 = 00000.
0833 CPC33 must be 00000 when CPC32 = 00000.
0834 CPC34 must be 00000 when CPC32 = 00000.
0835 CPC35 must be 00000 when CPC32 = 00000.
0840 CPC40 must be 00000 when CPC38 = 00000.
1014 CPC14 is not in decreasing positional order.
If non-zero, CPC14 must be less than CPC11.
1017 CPC17 is not in decreasing positional order.
If non-zero, CPC17 must be less than CPC14.
1020 CPC20 is not in decreasing positional order. If non-zero, CPC20 must be less than all non-
zero entries in CPC11, CPC14, and CPC17.
1023 CPC23 is not in decreasing positional order.
If non-zero, CPC23 must be less than CPC20.
1026 CPC26 is not in decreasing positional order.
If non-zero, CPC26 must be less than CPC23.
1029 CPC29 is not in decreasing positional order.
If non-zero, CPC29 must be less than all non-zero entries in CPC11, CPC14, CPC17, CPC20,
CPC23, and CPC26.
1032 CPC32 is not in decreasing positional order.
If non-zero, CPC32 must be less than CPC29.
1035 CPC35 is not in decreasing positional order. If non-zero, CPC35 must be less than CPC32.
1038 CPC38 is not in decreasing positional order. If non-zero, CPC38 must be less than all non-
zero entries in CPC11, CPC14, CPC17, CPC20, CPC23, CPC26, CPC29, CPC32, and
CPC35.
ID = 8
INC – Injection Configuration Block
Error Code Description ID = 8
0205 INC05 is out of range. Valid range is 00000
≤
INC05
≤
09999
0206 INC06 is out of range. Valid range is 00000
≤
INC06
≤
09999
0209 INC09 is out of range. Valid range is 00000
≤
INC09
≤
09999
0210 INC10 is out of range. Valid range is 00000
≤
INC10
≤
09999
0211 INC11 is out of range. Valid range is 00000
≤
INC11
≤
09999
0212 INC12 is out of range. Valid range is 00000
≤
INC12
≤
09999
0213 INC13 is out of range. Valid range is 00000
≤
INC13
≤
09999
0214 INC14 is out of range. Valid range is 00000
≤
INC14
≤
09999
0215 INC15 is out of range. Valid range is 00000
≤
INC15
≤
09999
