4–32 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 14
0222 PLC22 is out of range. Valid range is 00000
≤
PLC22
≤
09999
0223 PLC23 is out of range. Valid range is 00000
≤
PLC23
≤
09999
0224 PLC24 is out of range. Valid range is 00000
≤
PLC24
≤
09999
0225 PLC25 is out of range. Valid range is 00000
≤
PLC25
≤
09999
0226 PLC26 is out of range. Valid range is 00000
≤
PLC26
≤
09999
0227 PLC27 is out of range. Valid range is 00000
≤
PLC27
≤
09999
0228 PLC28 is out of range. Valid range is 00000
≤
PLC28
≤
09999
0229 PLC29 is out of range. Valid range is 00000
≤
PLC29
≤
09999
0230 PLC30 is out of range. Valid range is 00000
≤
PLC30
≤
09999
0231 PLC31 is out of range. Valid range is 00000
≤
PLC31
≤
09999
0232 PLC32 is out of range. Valid range is 00000
≤
PLC32
≤
09999
0233 PLC33 is out of range. Valid range is 00000
≤
PLC33
≤
09999
0234 PLC34 is out of range. Valid range is 00000
≤
PLC34
≤
09999
0235 PLC35 is out of range. Valid range is 00000
≤
PLC35
≤
09999
0236 PLC36 is out of range. Valid range is 00000
≤
PLC36
≤
09999
0237 PLC37 is out of range. Valid range is 00000
≤
PLC37
≤
09999
0238 PLC38 is out of range. Valid range is 00000
≤
PLC38
≤
09999
0239 PLC39 is out of range. Valid range is 00000
≤
PLC39
≤
09999
0240 PLC40 is out of range. Valid range is 00000
≤
PLC40
≤
09999
0243 PLC43 is out of range. Valid range is 00000
≤
PLC43
≤
09999
0244 PLC44 is out of range. Valid range is 00000
≤
PLC44
≤
09999
0247 PLC47 is out of range. Valid range is 00000
≤
PLC47
≤
09999
0248 PLC48 is out of range. Valid range is 00000
≤
PLC48
≤
09999
0249 PLC49 is out of range. Valid range is 00000
≤
PLC49
≤
09999
0250 PLC50 is out of range. Valid range is 00000
≤
PLC50
≤
09999
0251 PLC51 is out of range. Valid range is 00000
≤
PLC51
≤
09999
0252 PLC52 is out of range. Valid range is 00000
≤
PLC52
≤
09999
0253 PLC53 is out of range. Valid range is 00000
≤
PLC53
≤
09999
0254 PLC54 is out of range. Valid range is 00000
≤
PLC54
≤
09999
0343 PLC43 is equal to PLC44. They must not be equal.
0347 PLC47 is equal to PLC48. They must not be equal.
0441 PLC41 is out of range. Valid range is 00000
≤
PLC41 < PLC42
0442 PLC42 is out of range. Valid range is PLC41 < PLC42
≤
09999
0445 PLC45 is out of range. Valid range is 00000
≤
PLC45 < INC46
0446 PLC46 is out of range. Valid range is PLC45 < PLC46
≤
09999
0457 PLC57 is out of range.
If non-zero, PLC57 must be within MCC17 < PLC57
≤
MCC18
0502 Your bit pattern in PLC02-B02, PLC02-B01, and PLC02-B00 indicates a selected screw
RPM control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in PLC02-B06, PLC02-B05, and PLC02-B04 indicates a selected ram
(screw) backpressure control valve that is unconnected according to your entries in MCC02
and MCC04.
