Rockwell Automation 1771-QDC PLASTIC MOLD.MODULE User Manual

Page 199

3–23

Status Word/Bit Descriptions

Publication 1771-6.5.88 – July 1997

PTS

Word

Bit

Description

B03

Block contains trace #2 data

B04

Block contains trace #3 data

B05

Block contains trace #4 data

B06 - B14

Open

B15

Block contains phase/segment start information

PTS06

Trace data block number

B00

Block contains trace data points 1 to 50

B01

Block contains trace data points 51 to 100

B02

Block contains trace data points 101 to 150

B03

Block contains trace data points 151 to 200

B04

Block contains trace data points 201 to 250

B05

Block contains trace data points 251 to 300

B06

Block contains trace data points 301 to 350

B07

Block contains trace data points 351 to 400

B08 - B15

Reserved

PTS07, 08

Open

PTS09

Reports the time (in hundredths of seconds) after injection starts until the first trace data point is recorded.

PTS10

Reports how many data points (0 to 400) have been collected for the trace indicated in PTS05 and PTS06.
This value will not exceed the last data point for the block indicated in PTS06.

PTS11 - 14

Open

PTS15

Injection Segment 1 starting data point

one of PTS05-B01 to -B05 is set, PTS15 to PTS64 contain trace data. If PTS05-B15 is set, PTS15 to PTS48 contain

phase/segment start information. Each word contains starting data point (1 - 400) for the listed phase or segment.
If the phase or segment was not executed, this value will be zero.

PTS16

Injection Segment 2 starting data point

PTS17

Injection Segment 3 starting data point

PTS18

Injection Segment 4 starting data point

PTS19

Injection Segment 5 starting data point

PTS20

Injection Segment 6 starting data point

PTS21

Injection Segment 7 starting data point

PTS22

Injection Segment 8 starting data point

PTS23

Injection Segment 9 starting data point

PTS24

Injection Segment 10 starting data point

PTS25

Injection Segment 11 starting data point

PTS26

Pack Segment 1 starting data point

PTS27

Pack Segment 2 starting data point

PTS28

Pack Segment 3 starting data point

PTS29

Pack Segment 4 starting data point

PTS30

Pack Segment 5 starting data point

PTS31

Hold Segment 1 starting data point

PTS32

Hold Segment 2 starting data point

PTS33

Hold Segment 3 starting data point

PTS34

Hold Segment 4 starting data point

PTS35

Hold Segment 5 starting data point

PTS36

Pre-decompress starting data point

PTS37

Plastication Segment 1 starting data point

PTS38

Plastication Segment 2 starting data point

PTS39

Plastication Segment 3 starting data point
