3–16 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
IPS23 Actual Segment 4 Execution Time [21] Time required for last Segment 4.
IPS24 Actual End of Segment 4 Position [12] Ram (Screw) position at completion of last Segment 4.
IPS25 Actual Segment 5 Velocity [05] or [06] Average ram (screw) velocity during last Segment 5.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS26 Actual Segment 5 Pressure [01] Average ram (screw) pressure during last Segment 5.
IPS27 Actual Segment 5 Execution Time [21] Time required for last Segment 5.
IPS28 Actual End of Segment 5 Position [12] Ram (Screw) position at completion of last Segment 5.
IPS29 Actual Segment 6 Velocity [05] or [06] Average ram (screw) velocity during last Segment 6.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS30 Actual Segment 6 Pressure [01] Average ram (screw) pressure during last Segment 6.
IPS31 Actual Segment 6 Execution Time [21] Time required for last Segment 6.
IPS32 Actual End of Segment 6 Position [12] Ram (Screw) position at completion of last Segment 6.
IPS33 Actual Segment 7 Velocity [05] or [06] Average ram (screw) velocity during last Segment 7.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS34 Actual Segment 7 Pressure [01] Average ram (screw) pressure during last Segment 7.
IPS35 Actual Segment 7 Execution Time [21] Time required for last Segment 7.
IPS36 Actual End of Segment 7 Position [12] Ram (Screw) position at completion of last Segment 7.
IPS37 Actual Segment 8 Velocity [05] or [06] Average ram (screw) velocity during last Segment 8.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS38 Actual Segment 8 Pressure [01] Average ram (screw) pressure during last Segment 8.
IPS39 Actual Segment 8 Execution Time [21] Time required for last Segment 8.
IPS40 Actual End of Segment 8 Position [12] Ram (Screw) position at completion of last Segment 8.
IPS41 Actual Segment 9 Velocity [05] or [06] Average ram (screw) velocity during last Segment 9.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS42 Actual Segment 9 Pressure [01] Average ram (screw) pressure during last Segment 9.
IPS43 Actual Segment 9 Execution Time [21] Time required for last Segment 9.
IPS44 Actual End of Segment 9 Position [12] Ram (Screw) position at completion of last Segment 9.
IPS45 Actual Segment 10 Velocity [05] or [06] Average ram (screw) velocity during last Segment 10.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS46 Actual Segment 10 Pressure [01] Ram (screw) pressure during last Segment 10.
IPS47 Actual Segment 10 Execution Time [21] Time required for last Segment 10.
IPS48 Actual End of Segment 10 Position [12] Ram (Screw) position at completion of last Segment 10.
IPS49 Actual Segment 11 Velocity [05] or [06] Average ram (screw) velocity during last Segment 11.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS50 Actual Segment 11 Pressure [01] Average ram (screw) pressure during last Segment 11.
IPS51 Actual Segment 11 Execution Time [21] Time required for last Segment 11.
IPS52 Open
Injection Maximum Pressures
Word Description
IPS53 Maximum Ram (Screw) Pressure During Injection [01] Maximum instantaneous ram (screw) pressure during last profile.
IPS54 Maximum Cavity Pressure During Injection [04] Maximum instantaneous cavity pressure during last profile.
IPS55 - 60 Open
