4–45 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 21
0230 OPC30 is out of range.
When OPC03-B14 = 0, OPC30 must be within 00000
≤
OPC30
≤
09999
0233 OPC33 is out of range.
When OPC03-B14 = 0, OPC33 must be within 00000
≤
OPC33
≤
09999
0236 OPC36 is out of range.
When OPC03-B14 = 0, OPC36 must be within 00000
≤
OPC36
≤
09999
0239 OPC39 is out of range.
When OPC03-B14 = 0, OPC39 must be within 00000
≤
OPC39
≤
09999
0263 OPC63 is out of range. Valid range is 00000
≤
OPC63
≤
09999
0409 OPC09 is out of range.
When OPC03-B14 = 0, OPC39 must be within 00000
≤
OPC39
≤
09999
When OPC03-B14 = 1, a non-zero entry for OPC09 must be within FOC45
≤
OPC09
≤
FOC46
0410 OPC10 is out of range.
If non-zero, OPC10 must be within FOC41
≤
OPC10
≤
FOC42
0411 OPC11 is out of range.
if:
then:
MCC27 and MCC28 OPC11 must be within 00000
≤
OPC11
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC11 must be within 00000
≤
OPC11
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC11 must be within 00000
≤
OPC11
≤
MCC28 – MCC23.
MCC28 is non-zero
MCC27 and MCC28 OPC11 must be within 00000
≤
OPC11
≤
MCC24 – MCC23
are both zero
0412 OPC12 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC12 must be within
FOC45
≤
OPC12
≤
FOC46
0413 OPC13 is out of range.
If non-zero, OPC13 must be within FOC41
≤
OPC13
≤
FOC42
0414 OPC14 is out of range.
if:
then:
MCC27 and MCC28 OPC14 must be within 00000
≤
OPC14
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC14 must be within 00000
≤
OPC14
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC14 must be within 00000
≤
OPC14
≤
MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 OPC14 must be within 00000
≤
OPC14
≤
MCC24 – MCC23
are both zero
0415 OPC15 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC15 must be within
FOC45
≤
OPC15
≤
FOC46
0416 OPC16 is out of range.
If non-zero, OPC16 must be within FOC41
≤
OPC16
≤
FOC42
0417 OPC17 is out of range.
if:
then:
MCC27 and MCC28 OPC17 must be within 00000
≤
OPC17
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and OPC17 must be within 00000
≤
OPC17
≤
MCC24 – MCC27.
MCC28 is zero
MCC27 is zero and OPC17 must be within 00000
≤
OPC17
≤
MCC28 – MCC23
MCC28 is non-zero
If MCC27 and MCC28 OPC17 must be within 00000
≤
OPC17
≤
MCC24 – MCC23
are both zero
0418 OPC18 is out of range. When OPC03-B14 = 1, a non-zero entry for OPC18 must be within
SOC45
≤
OPC18
≤
SOC46
