2–88 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Bit-mapped Control Words
Word Bit Description
PPC01 Block ID = 00001111 (Low byte). High byte reserved for the module. Do not use.
PPC02 Open
PPC03 Configuration Selections
B00-B01 Profile Algorithm Selection
B01
B00
0 0 Ram (Screw) Press/Pos
0 1 Ram (Screw) Press/Time
1 0 RPM/Pos
1 1 RPM/Time
B02-B07 Open
B08 Plastication/Post-decompression Logical Bridge Selection End of Plastication Profile
= 0 Start Post-decompression Movement at End of Plastication Profile
= 1 Stop and Set-output at End of Plastication Profile
Module checks the state of this pause bit at completion of Plastication Profile to determine what further action to take:
if:
then the module:
SET sets its outputs to PLC33 - PLC40
RESET, SYS15-B15 = 1, immediately begins the Post-decompression Movement
and PSC05 > 00000
RESET, SYS15-B15 = 1, sets its outputs to PSC33 - PSC40
and PRC05 = 00000
RESET and SYS15-B12 = 0 sets its outputs to zero and latches SYS13-B10
B09-B11 Open
Profile Offset Sign Selection
B12 = 0 Plastication RPM Profile Offset is Positive
= 1 Plastication RPM Profile Offset is Negative
B13 = 0 Plastication Pressure Profile Offset is Positive
= 1 Plastication Pressure Profile Offset is Negative
B14-B15 Open
PPC04 Configuration Selections
Open/Closed Loop Selection
B00 = 0 Press/Pos Plastication Profiles Closed Loop
= 1 Press/Pos Plastication Profiles Open Loop
B01 = 0 Press/Time Plastication Profiles Closed Loop
= 1 Press/Time Plastication Profiles Open Loop
B02 = 0 RPM/Pos Plastication Profiles Closed Loop
= 1 RPM/Pos Plastication Profiles Open Loop
B03 = 0 RPM/Time Plastication Profiles Closed Loop
= 1 RPM/Time Plastication Profiles Open Loop
B04-B07 Open
ERC Enabled/Disabled Selection
B08 = 0 Press/Pos Plastication ERC On
= 1 Press/Pos Plastication ERC Off
B09 = 0 Press/Time Plastication ERC On
= 1 Press/Time Plastication ERC Off
B10 = 0 RPM/Pos Plastication ERC On
= 1 RPM/Pos Plastication ERC Off
B11 = 0 RPM/Time Plastication ERC On
= 1 RPM/Time Plastication ERC Off
B12-B15 Open
PPC05 - 08 Open
PPC – Plastication
Profile Block
