3–36 Status Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Bit Description
SYS13 B02 = 0 Normal
= 1 Second Clamp Close Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B01 is SET
S SYS15-B06 is RESET
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B01.
B03 = 0 Normal
= 1 Third Clamp Close Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B02 is SET
S
SYS15-B06 is RESET
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B02.
B04 = 0 Normal
= 1 Clamp Low Pressure Close Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B03 is SET
S SYS15-B06 is RESET
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B03.
B05 = 0 Normal
= 1 Injection Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B04 is SET
S SYS15-B08 is RESET
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B04.
B06 = 0 Normal
= 1 Pack Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B05 is SET
S
the Injection Profile completes
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B05.
B07 = 0 Normal
= 1 Hold Profile Command Error
The module latches this bit when both of the following are true:
S DYC02-B06 is SET
S SYS15-B11 is RESET
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B06.
B08 = 0 Normal
= 1 Pre-decompression Movement Command Error
The module latches this bit at completion of the Hold Profile if all of the following are true:
S HPC03-B08 is RESET
S HPC03-B09 is SET
S
SYS15-B12 is RESET
The module also latches this bit if all of the following are true:
S
DYC02-B07 is SET
S HPC03-B09 is SET
S SYS15-B12 is RESET
The module also latches this bit if both of the following are true:
S DYC02-B07 is SET
S SYS15-B11 is RESET
The module also latches this bit if both of the following are true:
S DYC02-B07 is SET
S PRC05 added to the actual ram (screw) position equals or exceeds MCC12
Module unlatches this bit when it decodes a valid DYC Block with any SET action execution bit other than DYC02-B07.
