1–23 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
End of Profile Set-output Values
OSC33 N43:509 Output #1
OSC34 N43:510 Output #2
OSC35 N43:511 Output #3
OSC36 N43:512 Output #4
OSC37 N43:513 Output #5
OSC38 N43:514 Output #6
OSC39 N43:515 Output #7
OSC40 N43:516 Output #8
Pressure Control Limits
OSC41 N43:517 Minimum limit
OSC42 N43:518 Maximum limit
OSC43 N43:519 % output for minimum
OSC44 N43:520 % output for maximum
Velocity Control Limits
OSC45 N43:521 Minimum limit
OSC46 N43:522 Maximum limit
OSC47 N43:523 % output for minimum
OSC48 N43:524 % output for maximum
Profile Tuning Constants
OSC49 N43:525 Proportional gain, pressure control
OSC50 N43:526 Integral gain, pressure control
OSC51 N43:527 Derivative gain, pressure control
OSC52 N43:528 Proportional gain, velocity control
OSC53 N43:529 Feedforward gain, velocity control
OSC54-56 N43:530-532 RFU
Setpoint for Profile Pressure Alarm
OSC57 N43:533 High pressure alarm
OSC58-64 N43:534-540 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PKC01 B38:8 Block ID 00000000 00001010
PKC02 B38:9 Selected valve configurations
PKC03-04 B38:10-11 RFU
Expert Response Compensation Percentage
PKC05 N44:121 ERC % minimum cavity pressure
PKC06 N44:122 ERC % minimum ram pressure
PKC07-08 N44:123-124 RFU
Set-output Values for Unselected Valves (During Profile)
PKC09 N44:125 Output #1
PKC10 N44:126 Output #2
PKC11 N44:127 Output #3
PKC12 N44:128 Output #4
PKC13 N44:129 Output #5
PKC14 N44:130 Output #6
PKC15 N44:131 Output #7
PKC16 N44:132 Output #8
PKC – Pack
Configuration Block
