4–55 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 24
0461 EPC61 is out of range.
if:
then:
MCC27 and MCC28 EPC61 must be within EPC62 < EPC61
≤
MCC28 – MCC27
are both non-zero
MCC27 is non-zero and EPC61 must be within EPC62 < EPC61
≤
MCC24 – MCC27
MCC28 is zero
MCC27 is zero and EPC61 must be within EPC62 < EPC61
≤
MCC28 – MCC23
MCC28 is non-zero
MCC27 and MCC28 EPC61 must be within EPC62 < EPC61
≤
MCC24 – MCC23
are both zero
0462 EPC62 is out of range. Valid range is 00000
≤
EPC62 < EPC61
0463 EPC63 is out of range. Valid range is EPC60
≤
EPC63 < EPC59
0503 Your selection to start the Ejector Profile based upon clamp position during the Clamp Open
Profile is invalid because QDC module does not have a valid OPC (SYS16-B04 = 0).
0504 You have selected closed-loop Press/Pos execution for the Ejector Profile by EPC04-B01 = 0;
however, your bit patterns in MCC02 and MCC03 indicate that the QDC module does not
have access to a connected ejector pressure transducer.
0600 Your entire Ejector Profile Command Block has been rejected because the QDC module does
not have both a valid Ejector Advance Configuration Command Block and a valid Ejector
Retract Configuration Command Block on-board.
0812 EPC12 must be 00000 when EPC11 = 00000.
0813 EPC13 must be 00000 when EPC11 = 00000.
0814 EPC14 must be 00000 when EPC11 = 00000.
0815 EPC15 must be 00000 when EPC14 = 00000.
0816 EPC16 must be 00000 when EPC14 = 00000.
0836 EPC36 must be 00000 when EPC35 = 00000.
0837 EPC37 must be 00000 when EPC35 = 00000.
0838 EPC38 must be 00000 when EPC35 = 00000.
0839 EPC39 must be 00000 when EPC38 = 00000.
0840 EPC40 must be 00000 when EPC38 = 00000.
1014 EPC14 is not in increasing positional order.
If non-zero, EPC14 must be greater than EPC11.
1038 EPC38 is not in decreasing positional order.
If non-zero, EPC38 must be less than EPC35.
ID = 25
DYC – Dynamic Command Block
Error Code Description ID = 25
0209 DYC09 is out of range. Valid range is 00000
≤
DYC09
≤
09999
0210 DYC10 is out of range. Valid range is 00000
≤
DYC10
≤
09999
0211 DYC11 is out of range. Valid range is 00000
≤
DYC11
≤
09999
0212 DYC12 is out of range. Valid range is 00000
≤
DYC12
≤
09999
0213 DYC13 is out of range. Valid range is 00000
≤
DYC13
≤
09999
0214 DYC14 is out of range. Valid range is 00000
≤
DYC14
≤
09999
0215 DYC15 is out of range. Valid range is 00000
≤
DYC15
≤
09999
0216 DYC16 is out of range. Valid range is 00000
≤
DYC16
≤
09999
0217 DYC17 is out of range. Valid range is 00000
≤
DYC17
≤
09999
0218 DYC18 is out of range. Valid range is 00000
≤
DYC18
≤
09999
0219 DYC19 is out of range. Valid range is 00000
≤
DYC19
≤
09999
0220 DYC20 is out of range. Valid range is 00000
≤
DYC20
≤
09999
