4–42 Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code Description ID = 18
0502 Your bit pattern in SOC02-B02, SOC02-B01, and SOC02-B00 indicates a selected clamp
velocity control valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in SOC02-B06, SOC02-B05, and SOC02-B04 indicates a selected clamp
pressure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 19 TOC – Third Clamp Open Configuration Block
Error Code Description ID = 19
0205 TOC05 is out of range. Valid range is 00000
≤
TOC05
≤
09999
0206 TOC06 is out of range. Valid range is 00000
≤
TOC06
≤
09999
0208 TOC08 is out of range. Valid range is 00000
≤
TOC08
≤
09999
0209 TOC09 is out of range. Valid range is 00000
≤
TOC09
≤
09999
0210 TOC10 is out of range. Valid range is 00000
≤
TOC10
≤
09999
0211 TOC11 is out of range. Valid range is 00000
≤
TOC11
≤
09999
0212 TOC12 is out of range. Valid range is 00000
≤
TOC12
≤
09999
0213 TOC13 is out of range. Valid range is 00000
≤
TOC13
≤
09999
0214 TOC14 is out of range. Valid range is 00000
≤
TOC14
≤
09999
0215 TOC15 is out of range. Valid range is 00000
≤
TOC15
≤
09999
0216 TOC16 is out of range. Valid range is 00000
≤
TOC16
≤
09999
0217 TOC17 is out of range. Valid range is 00000
≤
TOC17
≤
09999
0218 TOC18 is out of range. Valid range is 00000
≤
TOC18
≤
09999
0219 TOC19 is out of range. Valid range is 00000
≤
TOC19
≤
09999
0220 TOC20 is out of range. Valid range is 00000
≤
TOC20
≤
09999
0221 TOC21 is out of range. Valid range is 00000
≤
TOC21
≤
09999
0222 TOC22 is out of range. Valid range is 00000
≤
TOC22
≤
09999
0223 TOC23 is out of range. Valid range is 00000
≤
TOC23
≤
09999
0224 TOC24 is out of range. Valid range is 00000
≤
TOC24
≤
09999
0225 TOC25 is out of range. Valid range is 00000
≤
TOC25
≤
09999
0226 TOC26 is out of range. Valid range is 00000
≤
TOC26
≤
09999
0227 TOC27 is out of range. Valid range is 00000
≤
TOC27
≤
09999
0228 TOC28 is out of range. Valid range is 00000
≤
TOC28
≤
09999
0229 TOC29 is out of range. Valid range is 00000
≤
TOC29
≤
09999
0230 TOC30 is out of range. Valid range is 00000
≤
TOC30
≤
09999
0231 TOC31 is out of range. Valid range is 00000
≤
TOC31
≤
09999
0232 TOC32 is out of range. Valid range is 00000
≤
TOC32
≤
09999
0233 TOC33 is out of range. Valid range is 00000
≤
TOC33
≤
09999
0234 TOC34 is out of range. Valid range is 00000
≤
TOC34
≤
09999
0235 TOC35 is out of range. Valid range is 00000
≤
TOC35
≤
09999
0236 TOC36 is out of range. Valid range is 00000
≤
TOC36
≤
09999
0237 TOC37 is out of range. Valid range is 00000
≤
TOC37
≤
09999
0238 TOC38 is out of range. Valid range is 00000
≤
TOC38
≤
09999
0239 TOC39 is out of range. Valid range is 00000
≤
TOC39
≤
09999
0240 TOC40 is out of range. Valid range is 00000
≤
TOC40
≤
09999
0243 TOC43 is out of range. Valid range is 00000
≤
TOC43
≤
09999
0244 TOC44 is out of range. Valid range is 00000
≤
TOC44
≤
09999
0247 TOC47 is out of range. Valid range is 00000
≤
TOC47
≤
09999
