Id = 14 – Rockwell Automation 1771-QDC PLASTIC MOLD.MODULE User Manual
Page 255
4–31
Programming Error Codes
Publication 1771-6.5.88 – July 1997
Error Code
Description
ID = 13
0233
PRC33 is out of range. Valid range is 00000
≤
PRC33
≤
09999
0234
PRC34 is out of range. Valid range is 00000
≤
PRC34
≤
09999
0235
PRC35 is out of range. Valid range is 00000
≤
PRC35
≤
09999
0236
PRC36 is out of range. Valid range is 00000
≤
PRC36
≤
09999
0237
PRC37 is out of range. Valid range is 00000
≤
PRC37
≤
09999
0238
PRC38 is out of range. Valid range is 00000
≤
PRC38
≤
09999
0239
PRC39 is out of range. Valid range is 00000
≤
PRC39
≤
09999
0240
PRC40 is out of range. Valid range is 00000
≤
PRC40
≤
09999
0405
PRC05 is out of range.
if:
then:
MCC13 and MCC14
PRC05 must be within 00000
≤
PRC05
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and
PRC05 must be within 00000
≤
PRC05
≤
MCC10 – MCC13
MCC14 is zero
MCC13 is zero and
PRC05 must be within 00000
≤
PRC05
≤
MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14
PRC05 must be within 00000
≤
PRC05
≤
MCC10 – MCC09
are both zero
0457
PRC57 is out of range.
If non-zero, PRC57 must be within MCC17 < PRC57
≤
MCC18
0905
PRC05 is too large.
if:
then:
MCC13 and MCC14
PRC05 must be within MCC13 + PPC61 + PRC05
≤
MCC14
are both non-zero
MCC13 is zero and
PRC05 must be within MCC09 + PPC61 + PRC05
≤
MCC14
MCC14 is non-zero
MCC13 is non-zero and
PRC05 must be within MCC13 + PPC61 + PRC05
≤
MCC10
MCC14 is zero
MCC13 and MCC14
PRC05 must be within MCC09 + PPC61 + PRC05
≤
MCC10
are both zero
ID = 14
PLC – Plastication Configuration Block
Error Code
Description
ID = 14
0206
PLC06 is out of range. Valid range is 00000
≤
PLC06
≤
09999
0208
PLC08 is out of range. Valid range is 00000
≤
PLC08
≤
09999
0209
PLC09 is out of range. Valid range is 00000
≤
PLC09
≤
09999
0210
PLC10 is out of range. Valid range is 00000
≤
PLC10
≤
09999
0211
PLC11 is out of range. Valid range is 00000
≤
PLC11
≤
09999
0212
PLC12 is out of range. Valid range is 00000
≤
PLC12
≤
09999
0213
PLC13 is out of range. Valid range is 00000
≤
PLC13
≤
09999
0214
PLC14 is out of range. Valid range is 00000
≤
PLC14
≤
09999
0215
PLC15 is out of range. Valid range is 00000
≤
PLC15
≤
09999
0216
PLC16 is out of range. Valid range is 00000
≤
PLC16
≤
09999
0217
PLC17 is out of range. Valid range is 00000
≤
PLC17
≤
09999
0218
PLC18 is out of range. Valid range is 00000
≤
PLC18
≤
09999
0219
PLC19 is out of range. Valid range is 00000
≤
PLC19
≤
09999
0220
PLC20 is out of range. Valid range is 00000
≤
PLC20
≤
09999
0221
PLC21 is out of range. Valid range is 00000
≤
PLC21
≤
09999
