2–47 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
HDC
Profile Tuning Constants
Word Description
FOC49 Proportional Gain for Pressure Control [30]
FOC50 Integral Gain for Pressure Control [27] or [28]
FOC51 Derivative Gain for Pressure Control [26] or [21]
FOC52 Proportional Gain for Velocity Control [28]
FOC53 Feed Forward Gain for Velocity Control [30]
FOC54 - 56 Open
Profile Pressure Alarm Setpoint
Word Description
FOC57 Profile High Pressure Alarm Setpoint [02] The module compares real-time clamp pressure against this entry when executing the
First Clamp Open Profile. The module sets alarm status bit SYS06-B09 when clamp pressure equals or exceeds this entry during
the First Clamp Open Profile. A zero entry inhibits SYS06-B09.
FOC58 - 64 Open
Bit-mapped Control Words
Word Bit Description
HDC01 Block ID = 00001011 (Low byte). High byte reserved for the module. Do not use.
HDC02 Configuration Selections
B00-B02 Selected Cavity Pressure Control Valve
The module uses its algorithm to drive the following output during any Cav Press/Time Hold Profile.
B02 B01 B00
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
B03 Cavity Pressure Algorithm Selection
= 0 Dependent Gains (ISA)
= 1 Independent Gains (A-B)
B04-B06 Selected Ram (Screw) Pressure Control Valve
The module uses its algorithm to drive the following output during any Ram Press/Time Hold Profile.
B06 B05 B04
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 0 0 Output #5
1 0 1 Output #6
1 1 0 Output #7
1 1 1 Output #8
B07 Ram (Screw) Pressure Algorithm Selection
= 0 Dependent Gains (ISA)
= 1 Independent Gains (A-B)
B08-B15 Open
HDC03 - 04 Open
HDC – Hold Configuration Block
