1–4 Abbreviated Command and Status Blocks
Publication 1771-6.5.88 – July 1997
Important: If using Pro-Set 600 and a QDC module configured for
Clamp/Eject mode, this data is found in alternate files B35 and N41.
Word Pro-Set Address Description
Bit-mapped Control Words
DYC01 B34:24 Block ID 00011001 and jog commands
DYC02 B34:25 Action-execution commands
DYC03 B34:26 Miscellaneous commands
DYC04 B34:27 Status request and status clear commands
DYC05-06 B34:28-29 RFU
DYC07 B34:30 Process trace commands
(Series D and newer only)
DYC08 B34:31 Process trace data block request
(Series D and newer only)
Direct Set-output Values
DYC09 N40:121 Output #1
DYC10 N40:122 Output #2
DYC11 N40:123 Output #3
DYC12 N40:124 Output #4
DYC13 N40:125 Output #5
DYC14 N40:126 Output #6
DYC15 N40:127 Output #7
DYC16 N40:128 Output #8
Acceleration Ramp Rates
DYC17 N40:129 Output #1
DYC18 N40:130 Output #2
DYC19 N40:131 Output #3
DYC20 N40:132 Output #4
DYC21 N40:133 Output #5
DYC22 N40:134 Output #6
DYC23 N40:135 Output #7
DYC24 N40:136 Output #8
Deceleration Ramp Rates
DYC25 N40:137 Output #1
DYC26 N40:138 Output #2
DYC27 N40:139 Output #3
DYC28 N40:140 Output #4
DYC29 N40:141 Output #5
DYC30 N40:142 Output #6
DYC31 N40:143 Output #7
DYC32 N40:144 Output #8
DYC33-60 N40:145-172 RFU
Request for Programming Error
DYC61 N40:173 Fetch SYS61 and SYS62
DYC62-64 N40:174-176 RFU
DYC – Dynamic
Command Block
