2–48 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Expert Response Compensation (ERC) Percentage
Word Description
HDC05 Minimum Cav Press Control ERC Percentage [31] Although error coding allows range of 00000 to 09999, the module limits it to a
minimum of 01000.
HDC06 Minimum Ram Press Control ERC Percentage [31] Although error coding allows range of 00000 to 09999, the module limits it to a
minimum of 01000.
HDC07 - 08 Open
Unselected Valve Set-output Values
When the module starts the Hold Profile, it:
•
sets its unselected outputs to the values listed below
•
ignores the unselected value of the selected output
•
uses ramp rates HDC17 - HDC32 to ramp unselected outputs
Word Description
HDC09 Output #1 Set-output Value during Profile [19]
HDC10 Output #2 Set-output Value during Profile [19]
HDC11 Output #3 Set-output Value during Profile [19]
HDC12 Output #4 Set-output Value during Profile [19]
HDC13 Output #5 Set-output Value during Profile [19]
HDC14 Output #6 Set-output Value during Profile [19]
HDC15 Output #7 Set-output Value during Profile [19]
HDC16 Output #8 Set-output Value during Profile [19]
Output Ramp Rates
The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Hold Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).
Word Description
HDC17 Output #1 Acceleration Ramp Rate during Profile [20]
HDC18 Output #2 Acceleration Ramp Rate during Profile [20]
HDC19 Output #3 Acceleration Ramp Rate during Profile [20]
HDC20 Output #4 Acceleration Ramp Rate during Profile [20]
HDC21 Output #5 Acceleration Ramp Rate during Profile [20]
HDC22 Output #6 Acceleration Ramp Rate during Profile [20]
HDC23 Output #7 Acceleration Ramp Rate during Profile [20]
HDC24 Output #8 Acceleration Ramp Rate during Profile [20]
HDC25 Output #1 Deceleration Ramp Rate during Profile [20]
HDC26 Output #2 Deceleration Ramp Rate during Profile [20]
HDC27 Output #3 Deceleration Ramp Rate during Profile [20]
HDC28 Output #4 Deceleration Ramp Rate during Profile [20]
HDC29 Output #5 Deceleration Ramp Rate during Profile [20]
HDC30 Output #6 Deceleration Ramp Rate during Profile [20]
HDC31 Output #7 Deceleration Ramp Rate during Profile [20]
HDC32 Output #8 Deceleration Ramp Rate during Profile [20]
