Par 303, Par 304 – Rockwell Automation 20D PowerFlex 700S AC Drives with Phase II Control Programming Manual User Manual
Page 64
64
Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Chapter 2
Programming and Parameters
299 Elapsed
MWHrs
Displays the total energy the drive has consumed or produced. Calculated from the absolute magnitude of the
product of motor speed and motor torque (power), accumulated over time. This value will increase in both regen
and motoring modes of operation. This parameter value can be changed (written to) by the user.
Default:
Min/Max:
Units:
Scale:
0.0
0.0/429496736.0
MWhr
x 10
RW 32-bit
Integer
300
Motor Spd Fdbk
Displays measured motor speed information from the selected feedback device.
Default:
Min/Max:
Units:
Scale:
0.0000
-/+14112.0000
rpm
[Motor NP RPM] = 1.0 P.U.
RO Real
301 Motor
Speed
Ref
Displays the speed reference value, after the limit function. This is the input to the error calculator and speed
regulator.
Default:
Min/Max:
Units:
Scale:
0.0000
-/+14112.0000
rpm
[Motor NP RPM] = 1.0 P.U.
RO Real
302
Spd Reg PI Out
Displays the output of the speed regulator. This is the input to torque control. A value of 1.0 represents base
torque of the motor.
Default:
Min/Max:
Units:
0.0000
-/+8.0000 P.U.
P.U.
RO Real
303 Motor
Torque
Ref
Displays the reference value of motor torque. The actual value of the motor torque is within 5% of this value.
Default:
Min/Max:
Units:
0.0000
-/+8.0000 P.U.
P.U.
RO Real
304 Limit
Status
Displays the limit status of conditions that may be limiting the current reference or torque reference.
• Bit 0 “+MCS Iq Lim” indicates that torque producing current is at its positive limit.
• Bit 1 “+MCS Ws Lim” indicates that flux producing torque is at its positive limit.
• Bit 2 “0 Ia from +” indicates that torque producing current is limited to zero from the positive direction - refer to
[Iq Actual Lim].
• Bit 3 “+Iq Calc” indicates the calculation for torque producing current has reached its positive limit.
• Bit 4 “+Current Lim” indicates that the current reference has reached the positive Motor Current Limit set by
• Bit 5 “+DriveProtOL” indicates that the current reference has reached the positive current limit set by the Open Loop Inverter Overload, shown in
[OL OpnLp CurrLim].
• Bit 6 “+DriveProtCL” indicates that the current reference has reached the positive current limit set by the Closed Loop Inverter Overload, shown in
[OL ClsLp CurrLim].
• Bit 8 “+Torq Limit” indicates that the torque reference has reached the Positive Torque Limit set by
[Torque Pos Limit].
• Bit 9 “Mtrng PwrLim” indicates that the torque reference is being limited by the Motoring Power Limit set by
[Mtring Power Lim].
• Bit 10 “+Torq CurLim” indicates that current reference has reached the Actual Torque Producing Current Limit set by Par 353 [Iq Actual Lim].
• Bit 11 “Atune Tq Lim” indicates that the torque reference is being limited by
[Atune Trq Ref].
• Bit 12 “+0 Torq Ena” indicates that the torque reference is limited to zero because
[Logic Ctrl State] bit 9 “Torq Ref En” is off.
• Bit 13 “+0 Curr Ena” indicates that the current reference is limited to zero because Par 157 [Logic Ctrl State] bit 11 “CurrRef En” is off.
• Bit 14 “Speed Limit” indicates the collective status of all speed limitations.
• Bit 15 “Current Lim” indicates the collective status of all current limitations
• Bit 16 “-MCS Iq Lim” indicates that torque producing current is at its negative limit.
• Bit 17 “-MCS Ws Lim” indicates that flux producing torque is at its negative limit.
• Bit 18 “0 Ia from -” indicates that torque producing current is limited to zero from the negative direction - refer to
[Iq Actual Lim].
• Bit 19 “-Iq Calc’ indicates the calculation for torque producing current has reached its negative limit.
• Bit 20 “-Current Lim” indicates that the current reference has reached the negative Motor Current Limit set by
[Mtr Current Lim].
• Bit 21 “-DriveProtOL” indicates that the current reference has reached the negative current limit set by the Open Loop Inverter Overload, shown in
[OL OpnLp CurrLim].
• Bit 22 “-DriveProtCL” indicates that the current reference has reached the negative current limit set by the Closed Loop Inverter Overload, shown in
[OL ClsLp CurrLim].
• Bit 24 “-Torq Limit” indicates that the torque reference has reached the Negative Torque Limit set by
[Torque Neg Limit].
• Bit 25 “Regen PwrLim” indicates that the torque reference is being limited by the Regenerative Power Limit set by
[Regen Power Lim].
• Bit 26 “-Torq CurLim” indicates that current reference has reached the Actual Torque Producing Current Limit set by
[Iq Actual Lim].
• Bit 27 “Bus Reg Tq Lim” indicates the bus voltage regulator is active and limiting the regenerative torque.
• Bit 28 “-0 Torq Ena” indicates that the torque reference is limited to zero because
[Logic Ctrl State] bit 9 “Torq Ref En” is off.
• Bit 29 “-0 Curr Ena” indicates that the current reference is limited to zero because Par 157 [Logic Ctrl State] bit 11 “CurrRef En” is off.
• Bit 30 “Torque Limit” indicates the collective status of all torque limitations.
• Bit 31 “Power Limit” indicates the collective status of all power limitations.
305
Mtr Trq Curr Ref
Displays the torque current reference present at the output of the current rate limiter. 100% is equal to 1 per unit
(P.U.) rated motor torque.
Default:
Min/Max:
Units:
0.0000
-/+8.0000 P.U.
P.U.
RO Real
306
DC Bus Voltage
Displays measured bus voltage.
Note: The maximum value was increased from 1000.0000 to 1170.0000 for firmware version 3.001.
Default:
Min/Max:
Units:
0.0000
0.0000/1170.0000
V
RO Real
307 Output
Voltage
Displays RMS line-to-line fundamental motor voltage. This data is averaged and updated every 50 milliseconds.
Default:
Min/Max:
Units:
0.00
0.00/3000.00
V
RO Real
308 Output
Current
Displays measured RMS motor current.
Default:
Min/Max:
Units:
0.00
0.00/10000.00
A
RO Real
No.
Name
Description
Values
Link
able
Re
ad
-Write
Da
ta
T
yp
e
Options
Po
w
er
L
im
it
To
rq
ue
L
im
it
-0 C
urr E
nbl
-0 T
rq Enbl
Bus
Re
g Li
m
-T
rq
C
ur
Li
m
Re
gen P
w
rLi
m
-T
rq
L
im
it
Spd
Reg
O
pen
-D
riv
ePr
otCL
-D
riv
ePr
otOL
-C
ur
re
nt
Li
m
-Iq C
alc
0 Iq fr
om -
-MCS
W
s
Lim
-MCS
Iq
Lim
Cu
rr
en
t L
im
Spe
ed Limit
+0 C
urr E
nb
l
+0 T
rq E
nbl
At
un
T
rq
L
im
+T
rq
C
urLim
Mt
rn
g PwrLim
+T
rq Li
mi
t
+
Sp
dR
eg
Op
en
+D
riv
eP
rotCL
+D
riv
eP
rotO
L
+C
urr
ent Li
m
+Iq Cal
c
0 Iq fr
om +
+MCS W
s Lim
+MCS Iq Lim
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
0 = False
1 = True
