VoltageFdbk Loss
2
A loss of motor or DC Bus voltage feedback has occurred because of a
communication failure between Motor Control and Voltage Feedback board.
• Check the communication line between Motor
Control (MC) and the Voltage Feedback board.
• Replace the Voltage Feedback board.
Configured with
[VoltFdbkLossCnfg].
44
Runtime Data Rst
3
Runtime data (hours, energy) has been reset to zero due to a checksum error. (Informational Only)
45
Enable Health
1
The safety circuit is active.
Check the input signal to the safety circuit.
46
Interp Out Synch
2
The interpolator for position feedback lost synchronization with the Velocity
Position Loop (VPL).
[Interp Flt Cnfg].
47
MC CML Task Fail
3
The Current Minor Loop (CML) task has been delayed or run with an incorrect
interval.
Cycle power to the drive.
48
No Ctrl Device
1
The controlling device (HIM or controller) has been disconnected while the
drive was running.
Check the controlling device connections to the drive.
49
DPI Loss Port 1
2
The device at DPI port 1 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 1.
Configured with
[DPI CommLoss Cfg].
50
DPI Loss Port 2
2
The device at DPI port 2 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 2.
Configured with
[DPI CommLoss Cfg].
51
DPI Loss Port 3
2
The device at DPI port 3 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 3.
Configured with
[DPI CommLoss Cfg].
52
DPI Loss Port 4
2
The device at DPI port 4 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 4.
Configured with
[DPI CommLoss Cfg].
53
DPI Loss Port 5
2
The device at DPI port 5 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 5.
Configured with
[DPI CommLoss Cfg].
54
DPI Loss Port 6
2
The device at DPI port 6 has stopped communicating with the drive.
A SCANport device is connected to a drive operating DPI devices at 500k Baud.
Verify that the DPI device is present and functional at
port 6.
Configured with
[DPI CommLoss Cfg].
55
Net Loss DPI P1
2
A communications fault has occurred between the communication adapter at
DPI port 1 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
56
Net Loss DPI P2
2
A communications fault has occurred between the communication adapter at
DPI port 2 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
57
Net Loss DPI P3
2
A communications fault has occurred between the communication adapter at
DPI port 3 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
58
Net Loss DPI P4
2
A communications fault has occurred between the communication adapter at
DPI port 4 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
59
Net Loss DPI P5
2
A communications fault has occurred between the communication adapter at
DPI port 5 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
60
Net Loss DPI P6
2
A communications fault has occurred between the communication adapter at
DPI port 6 and the network.
Verify the network connection.
Verify the status of network.
Configured with
[NetLoss DPI Cnfg].
61
Logix Out of Run
2
The DriveLogix controller is in a Non-Run mode. Non-Run modes include
program, remote-program and faulted modes.
Clear the fault.
Configured with
[Lgx OutOfRunCnfg].
62
Logix Timeout
2
The communication connection to the DriveLogix controller has timed out.
Configured with
[Lgx Timeout Cnfg].
63
Logix Closed
2
The DriveLogix controller has closed the Controller to Drive connection.
Verify that the Drive is present in the Controller I/O
configuration.
Configured with
[Lgx Clod Cnfg].
64
Logix Link Chng
2
A required link in the Controller to Drive Communication Format has been
modified.
Clear the fault.
Configured with
[Lgx LinkChngCnfg].
65
HiHp In PhaseLs
2
(High Horse Power Only)
AC Input Phase Loss - the AC input phase voltage has fallen.
• Check for voltage on each AC input phase.
• Check the status of each external AC input fuse.
Configured with
[HiHp InPhsLs Cfg].
