168 Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Appendix B Application Notes
Motors with Compatible
Thermistor Ratings
Motor Type
Motor
(kW)
Type
(Catalog No.)
(1)
Poles Base Speed (RPM)
Voltage
(Vrms)
Rated Current
(Arms) Ex. Current (Arms) GD2 (Kg/m
2
)
200 STD Motor 1.5 M-51027 4 1500 180 7.5 - 0.024
2.2 M-51028 4 1500 180 11 - 0.045
3.7 M-51001 4 1500 180 18 - 0.066
3.7 M-51007-1 4 1500 180 18 - 0.066
5.5 M-51002 4 1500 180 25 - 0.12
5.5 M-51008-1 4 1500 180 25 - 0.12
7.5 M-51003 4 1500 180 33 - 0.15
7.5 M-51009-1 4 1500 180 33 - 0.15
11 M-51004 4 1500 180 47 - 0.32
11 M-51010-1 4 1500 180 47 - 0.32
15 M-51005 4 1500 180 63 - 0.43
15 M-51011-1 4 1500 180 63 - 0.43
18.5 M-51012 4 1500 180 81 - 0.71
18.5 M-51012-1 4 1500 180 81 - 0.71
22 M-51013 4 1500 180 95 - 0.82
22 M-51013-1 4 1500 180 95 - 0.82
30 M-51050 4 1500 155 145 - 0.83
37 M-51051 4 1500 155 183 - 1.1
45 M-51052 4 1500 155 220 - 1.4
55 M-51053 4 1500 155 265 - 2
75 M-51054 4 1500 155 346 - 2.7
200 SVO Motor 0.75 M-51043 4 1500 140 5.3 - 0.0075
1.5 M-51015 4 1500 140 11.4 - 0.0100
2.2 M-51016 4 1500 140 15 - 0.0120
3.7 M-51017 4 1500 140 24.5 - 0.0180
5.5 M-51018 4 1500 140 34.8 - 0.0390
7.5 M-51019 4 1500 140 44 - 0.0470
11 M-51020 4 1500 140 67.1 - 0.0810
15 M-51021 4 1500 140 80.7 - 0.1370
22 M-51022 4 1500 140 120 - 0.2000
30 M-51023 6 1000 155 176 - 0.5800
37 M-51024 6 1000 155 210 - 0.7000
55 M-51026 6 1000 135 334 - 1.1000
55 M-51027 6 500 155 315 - 4.0000
400 STD Motor 1.5 MC-M2051 4 1500 320 4.7 2.0045 -
2.2 MC-M2052 4 1500 320 6.3 3.24 -
3.7 MC-M2053 4 1500 320 10 5.25 -
5.5 MC-M2054 4 1500 320 15.5 8.8 -
7.5 MC-M2055 4 1500 320 20.5 11.25 -
11 MC-M2056 4 1500 320 29 14.3 -
15 MC-M2057 4 1500 320 37 16.4 -
18.5 MC-M2058 4 1500 320 45 19.65 -
22 MC-M2059 4 1500 320 53 23 -
30 MC-M2060 4 1500 320 71 28.15 -
37 MC-M2061 4 1500 320 85 29.7 -
45 MC-M2062 4 1500 320 97 30.55 -
55 MC-M2063 4 1500 320 121 - -
75 MC-M2064 4 1500 320 163 - -
90 MC-M2065 4 1500 320 188 - -
110 MC-M2066 4 1500 320 227 - -
132 MC-M2067 4 1500 320 280 - -
160 MC-M2068 4 1500 320 335 - -
200 MC-M2069 4 1500 320 375 - -
