158 Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Appendix A Human Interface Module Overview
Preferences Menu
The HIM and drive have features that you can customize.
The PowerFlex 700S drive is initially set to Basic Parameter View. To view all
parameters, set parameter 196 [ParamAccessLvl] to option 1 “Advanced”.
Parameter 196 is not affected by the Reset to Defaults function.
View and Edit Parameters LCD HIM
Numeric Keypad Shortcut
If using a HIM with a numeric keypad, press the ALT key and the +/– key to
access the parameter by typing its number.
Option Description
Drive Identity Add text to identify the drive.
Change Password Enable/disable or modify the password.
User Dspy Lines Select the display, parameter, scale and text for the User Display. The User Display is two lines of
user-defined data that appears when the HIM is not being used for programming.
User Dspy Time Set the wait time for the User Display or enable/disable it.
User Dspy Video Select Reverse or Normal video for the Frequency and User Display lines.
Reset User Dspy Return all the options for the User Display to factory default values.
Steps: Key(s): Example Displays”
1. In the Main Menu, press the Up Arrow or Down Arrow to scroll
to “Parameter.”
2. Press Enter. “FGP File” appears on the top line and the first
three files appear below it.
3. Press the Up Arrow or Down Arrow to scroll through the files.
4. Press Enter to select a file. The groups in the file are displayed
under it.
5. Repeat steps 3 and 4 to select a group and then a parameter.
The parameter value screen will appear.
6. Press Enter to edit the parameter.
7. Press the Up Arrow or Down Arrow to change the value. If
desired, press Sel to move from digit to digit, letter to letter,
or bit to bit. The digit or bit that you can change will be
highlighted.
8. Press Enter to save the value. If you want to cancel a change,
press Esc.
9. Press the Up Arrow or Down Arrow to scroll through the
parameters in the group, or press Esc to return to the group
list.
Sel
Esc
or
or
or
or
F GP: File
Monitor
Motor Control
Dynamic Control
FGP: Par 2
Motor NP FLA
1.000 Amps
[ALT][VIEW] -> Limits
FGP: Par 2
Motor NP FLA
1.500 Amps
[ALT][VIEW] -> Limits
F G P: Group
Motor Data
Monitoring
Drive Config
FG P : Parameter
Motor NP Volts
Motor NP FLA
Motor NP Hertz
