Chapter 2
Programming and Parameters
245
Spd Fdbk TP Sel
Enter or write a value to select the data displayed in
[Spd Fdbk TP RPM] and
[Spd Fdbk TP Data].
Note: Option values 5 - 15 were changed to “Reserved” and option 41 “First Diff” was added for firmware version
2.004.
Default:
Options:
0 =
0 =
1 =
2 =
3 =
4 =
5 =
6 =
7 =
8 =
9 =
10 =
11 =
12 =
13 =
14 =
15 =
16 =
17 =
18 =
19 =
20 =
“Zero”
“Zero”
21 = “E0 EPR”
“Clock Time”
22 = “E0 Edge Mode”
“InactvFbkDev”
23 = “E0 nMax”
“ActiveFbkDev”
24 = “E0 Error”
“MCP Fdbk Dev”
25 = “E0 Qloss pk”
“Reserved”
26 = “E0 Ploss pk”
“Reserved”
27 = “E0 PlevlHist”
“Reserved”
28 = “E1 Edge Time”
“Reserved”
29 = “E1 dEdge”
“Reserved”
30 = “E1 dTime”
“Reserved”
31 = “E1 EPR”
“Reserved”
32 = “E1 Edge Mode”
“Reserved”
33 = “E1 nMax”
“Reserved”
34 = “E1 Error”
“Reserved”
35 = “E1 Qloss pk”
“Reserved”
36 = “E1 Ploss pk”
“MCP PPR”
37 = “E1 PlevlHist”
“MCP 2^n”
38 = “E0 Delta2Err”
“E0 Edge Time”
39 = “E1 Delta2Err”
“E0 dEdge”
40 = “EOB Present”
“E0 dTime”
41 = “First Diff”
246
Spd Fdbk TP RPM
Displays the value selected in
[Spd Fdbk TP Sel] in rpm. This display should only be used if the selected
value is floating point data.
Default:
Min/Max:
Units:
Scale:
0.0
-/+8.0 P.U.
rpm
[Motor NP RPM] = 1.0 P.U.
RO Real
247
Spd Fdbk TP Data
Displays the value selected in
[Spd Fdbk TP Sel]. This display should only be used if the selected value is
integer data.
Default:
Min/Max:
0
-/+32768
RO 16-bit
Integer
249
Fdbk Option ID
Displays information about the Feedback Option.
• Bits 15-11 indicate Module ID Number.
• Bits 10-6 indicate Version Number.
• Bits 5-3 indicate Revision Number High.
• Bits 2-0 indicate Revision Number Low.
Hexadecimal 1000 indicates resolver, hexadecimal 2000 indicates old high-resolution board, and hexadecimal
2040 indicates new high-resolution board.
Options:
250
FB Opt0 Posit
Displays the position feedback (accumulator) from the feedback option card port 0.
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
251
FB Opt0 Spd Fdbk
Displays the speed feedback from the feedback option card port 0.
Default:
Min/Max:
Units:
Scale:
0.0000
-/+14000.0000
rpm
[Motor NP RPM] = 1.0 P.U.
RO Real
252
FB Opt1 Posit
Displays position feedback (accumulator) from port 1 of the feedback option card.
Default:
Min/Max:
0
0/2147483648
RO 32-bit
Integer
253
FB Opt1 Spd Fdbk
Displays speed feedback from port 1 of the feedback option card.
Default:
Min/Max:
Units
0.0
-/+8.0 P.U.
rpm
RO Real
No.
Name
Description
Values
Link
able
Re
ad
-Write
Da
ta
T
yp
e
N N NNN
N N NNN
N NNN
Module ID No.
Version No.
Revision No. Low
N NNN
Revision No. High
