60
Rockwell Automation Publication 20D-PM001C-EN-P - July 2013
Chapter 2
Programming and Parameters
270
Reslvr0 TP Sel
Enter or write a value to select Fault data displayed in
Default:
Options:
0 =
0 =
1 =
2 =
3 =
“Zero”
“Zero”
4 = “R0 EPR”
“R0 Edge Time”
5 = “R0 Edge Mode”
“R0 dEdge”
6 = “R0 nMax”
“R0 dTime”
7 = “R0 Delta2Err”
271
Reslvr0 TP Data
Displays the data selected by
[Reslvr0 TP Sel].
Default:
Min/Max:
0
-/+2147483648
RO 32-bit
Integer
272 Reslvr0
SpdRatio
Specifies the speed ratio for the resolver option card port 0. The speed ratio comes from the following formula.
Speed ratio = electrical revolutions / mechanical revolutions = pole count / 2.
Note: Option 0 = “Zero” was added for firmware version 2.004.
Default:
Options:
1 =
0 =
1 =
2 =
2 poles (x1)
“Zero”
3 = 6 Poles (x3)
2 Poles (x1)
4 = 8 Poles (x4)
4 Poles (x2)
5 = 10 Poles(x5)
273 Reslvr0
Carrier
Specifies the resolver carrier frequency for the resolver option card port 0.
Default:
Min/Max:
Units:
0
0/10000
Hz
RO 32-bit
Integer
274
Reslvr0 In Volts
Specifies the resolver input voltage for the resolver option card port 0.
Default:
Min/Max:
Units:
0.0000
0.0000/31.0810
V
RO Real
275 Rslvr0
XfrmRatio
Specifies the resolver transform ratio for the resolver option card port 0.
Default:
Min/Max:
0.0000
0.0000/4.0950
RO Real
276 Reslvr0
CableBal
Specifies the resolver cable balance for the resolver option card port 0.
Default:
Min/Max:
0
0/255
RO Real
277
Reslvr0 Type Sel
Specifies used resolver.
The values for options 5 & 12 were changed to “Reserved” for firmware version 2.004. Added options 15 and 16
for firmware version 4.001 but are not functional (for future use).
Default:
Options:
0 =
0 =
1 =
2 =
3 =
4 =
5 =
6 =
7 =
8 =
“Disabled”
“Disabled”
9 = “1326Ax 460v”
“T2014/2087x1”
10 = “Reserved”
“T2014/2087x2”
11 = “Reserved”
“T2014/2087x5”
12 = “Reserved”
“MPL 460v”
13 = “Reserved”
“Reserved”
14 = “AmciR11XC107”
“Siemens 1FT6”
15 = “PowerTec R1”
“PrkrHn ZX600”
16 = “PowerTec R2”
“Reserved”
No.
Name
Description
Values
Link
able
Re
ad
-Write
Da
ta
T
yp
e
