Chapter 29: System Maintenance and Administration
Avidia System Configuration and Management User Manual 571
4 Click Ping .
The Ping window displays one of the following messages (where xxx.xxx.xxx.xxx is the IP
address of the target network device:
The Ping window also displays the following statistics:
M
ANAGING
I
MAGE
F
ILES
In the Image Manager window, you can download, upload, copy and delete Avidia system files.
It is recommended that you upload a copy of all configuration files to a TFTP server, so that you
can easily download and restore them if they get corrupted.
To open the Image Manager window, do one of the following:
• In the Site Map Navigation window, click Image Manager .
• In the Tree Navigation window, click System Maintenance , Image Manager .
Message Description
xxx.xxx.xxx.xxx is alive. The target device is online.
No answer from xxx.xxx.xxx.xxx. The target device is not responding.
Ping xxx.xxx.xxx.xxx -- 5 second time
out occurred. The target device will be pinged again in five
seconds.
xxx.xxx.xxx.xxx statistics: ??% loss The percentage (where?? is the percentage) of
ping packets that were not sent successfully to the
target device.
Information Description
Packet Sent The total number of ping packets sent to the
remote address.
Retries The number of ping packets that were resent.
Successes The number of ping packets sent successfully to
the remote address.
Failures The number of ping packets that were not sent
successfully to the remote address.
