Chapter 8: Configuring ATM Virtual Circuits
Avidia System Configuration and Management User Manual
187
The following screen illustrates an example of both show PVCC commands.
The following table describes the information displayed after you type a show pvc command.
Column
Description
Index
The PVCC table index number of the displayed PVCC.
Admin
The administrative status of the PVCC. Up indicates active. Down indicates inactive.
Oper
The operational status of the PVCC. Up indicates operational and passing data. Down
indicates not operational.
Channel Port
The channel card slot and port.
VCI
The channel card VCI.
Type
The type of service on the line. Currently, Transparent LAN Service is the only supported
service, therefore TLS displays.
Encap
The encapsulation mode.
Line Port
The line card port number.
VPI
The line card VPI.
VCI
The line card VCI.
TxIDx
The ATM traffic profile assigned for transmitted traffic.
RxIDx
The ATM traffic profile assigned for received traffic.
::pvc=> show
Channel
Line
Index
Admin
Oper Port
VCI
Type
Encap
Port
VPI
VCI
TxIDx
RxIDx
2
up
up
2.1
50
TLS
vcmux
12.1
50
100
2
2
3
down
down 2.2
51
TLS
vcmux
12.1
50
101
2
3
::pvc=> show 2 0 50
Channel
Line
Index
Admin
Oper Port
VCI
Type
Encap
Port
VPI
VCI
TxIDx
RxIDx
2
up
up
2.1
50
TLS
vcmux
12.1
50
100
2
2
