Chapter 8: Configuring ATM Virtual Circuits

Avidia System Configuration and Management User Manual

161

Examples

::aps=> show

::aps=> show 12

A screen similar to the following displays.

Information

Description

Slot

The slot for which the APS configuration is displayed.

Enable

Whether APS is enabled or disabled for the slot.

Mode

The configured APS mode Options:

•

autonorev

(non revertive auto switch)—once traffic has

switched to the protection channel it will automatically switch back
to the working channel when the system detects an error on the
protection channel and the failure on the working channel has been
cleared.

•

norev

(non revertive manual)—once traffic has switched to the

protection channel it will not automatically switch back to the
working channel when the failure on that channel has been cleared
(this is the default).

•

rev

(revertive)—once traffic has switched to the protection

channel, it will automatically switch back to the working channel
when the failure on the working channel has been cleared for a
user-specified amount of time.

WTR

When the APS is set to rev, this parameter specifies the number of
seconds the system waits before switching traffic from the protection
channel back to the working channel after a failure on the main channel
has been cleared. The range is 300 to 720 seconds. The default is 300
seconds.

Command

Which, if any, manual APS commands are in effect.

TrapEn

Whether APS trap generation is enabled or disabled.
