Configuring Frame Relay FRF.8 Circuits
212
Avidia System Configuration and Management User Manual
Adding a Frame Relay FRF.8 Circuit
From the
::frf8=>
prompt, type the new command in the following format then press
. The index number and the frame relay VPI/VCI on the frame card are automatically
assigned.
new
[-admin (up|down)] [-lpmode (1|2)] [-lpvalue (0|1)]
[-cimode (1|2)] [-demode (1|2)] [-devalue (0|1)] [-CIR
[-Be
Parameters
The frame card slot and port.
The DLCI (Data Link Connection Identifier) is the logical channel a data frame travels
from the transmitted device to the destination device. The valid range is 16 to 991.
The line card slot and port (format slot.port).
The ATM VPI of the frame relay (fr) VCC between the frame channel card and the line
card.
The ATM VCI of the fr VCC between the frame channel card and the line card.
[-admin (up|down)]
The administrative status of the line.
up
activates the port,
down
deactivates the port.
ENTER
