Configuring Bridging and Routing Sessions
232 Avidia System Configuration and Management User Manual
[-encap(llc-snap|vcmuxbr|vcmuxrt)]
The encapsulation mode you want to use for this PVC. The type of service specified for the
-service parameter determines the appropriate encapsulation modes. In addition, the
configured encapsulation mode must match the encapsulation mode used by the adjacent
segments in the network.
[-stppri ]
Omit this parameter if you specified route or broute for the service type. This
parameter sets the STP priority for the session. The valid range is from 0 to 255, with 0
being the highest priority. The default value is 128.
[-stpcost ]
Omit this parameter if you specified route or broute for the service type. This
parameter sets the STP path cost for the session. The valid range is from 1 to 65535. The
value 1 is the lowest cost, reflecting the greatest efficiency. The default value is 250 for
WAN ports and 100 for LAN ports.
Example
::session=> modify 2 -admin down -subs company123 -service broute
-ipaddr 10.0.1.9 -mask 255.0.0.0 -encap llc-snap -stppri 128
-stpcost 250
If you specified service type: Set the encapsulation mode to:
broute llc-snap
route llc-snap or vcmuxrt
bridge for SDSL—vcmuxbr
for all other cards—vcmuxbr or
llc-snap
