Chapter 20: Configuring Subscriber Services
Avidia System Configuration and Management User Manual
413
3
In the
Clock Source
box, select the transmit clock source for the IDSL card (
Local
,
System
A
,
or
System B
).
•
Local
—The IDSL card derives timing from the IDSL card clock.
•
System A
—The IDSL card derives timing from the Avidia system reference clock on
channel A.
•
System B
—The IDSL card derives timing from the Avidia system reference clock on
channel B.
4
In the
Line Profile
boxes, type the desired line profile index for each port you want to
configure.
Click the
Line Profile Browse
button
to display the configured profiles. If the desired profile
is not yet configured, you can configure it now. See
“Configuring IDSL Line Profiles” on
for instructions.
5
In the
Alarm Profile
boxes, type the desired alarm profile index for each port you want to
configure.
Click the
Alarm Profile Browse
button
to display the configured profiles. If the desired profile
is not yet configured, you can configure it now. See
“Configuring IDSL Alarm Profiles” on
for instructions.
6
In the
Circuit ID
boxes, enter the circuit identifier for the port.
The circuit ID is the transmission vendor’s circuit identifier for the port. This identifier,
which can facilitate troubleshooting, can be up to 255 characters.
7
Do one of the following:
•
Click
Set
to activate the new settings.
•
Click
Get
to cancel the new settings. You can only cancel the settings if you have not
clicked
Set
.
•
In the
Slot
box select the slot number to configure ports on another card.
