Chapter 22: Configuring ATM Virtual Circuits
Avidia System Configuration and Management User Manual
455
Click
and
if necessary to view the entire table.
displays the beginning of the table.
displays the next page of the table. The SPVC Configuration table displays the following
information for each SPVC.
Information Description
Admin Status
The SPVC administrative status. Options:
•
Up—activated
•
Down—deactivated
Oper Status
The SPVC operational status. Options:
•
In Progress—attempting to connect
•
Connected—operational
•
Retries Exhausted—not operational
Source Slot
The channel card slot number.
Source VPI
The VPI of the PVCC between the CPE and the line card.
Source VCI
The VCI of the PVCC between the CPE and the line card.
Source Encap
The PVCC encapsulation type (applies to frame channel cards
only). Options:
•
LLC_8023
•
VC_MUX_8023
Destination Address
The ATM address of the destination ATM end system.
Destination Retry Interval
The number of seconds the system waits before attempting
to re-establish the SPVC after a failed call attempt (range: 0 to
3600).
Destination Retry Limit
The maximum allowable number of unsuccessful call setup
attempts (range: 0 to 65535).
Last Rel. Cause
The reason the SPVC was last disabled. This displays as a
numeric code. See
“SPVC Last Release Cause Codes” on
for code definitions.
Tx Idx
The traffic descriptor profile index assigned to the SPVC
transmitted traffic.
Rx Idx
The traffic descriptor profile index assigned to the SPVC
received traffic.
