Configuring SDSL Frame Line Profiles
394 Avidia System Configuration and Management User Manual
Adding SDSL Frame Line Profiles
Fixed Rate is the only supported Rate Mode , therefore you do not need to select a Rate Mode
setting.
1 In the Rate (Kbps) box, type the transmit rate in Kbps.
The valid range supported by the SDSL card is from 64 to 2,048, in increments of 64.
However, the specified rate must be supported by the remote modem. See the remote
modem documentation to verify the supported data rates.
2 Click Add to add the SDSL line profile.
Deleting SDSL Frame Line Profiles
1 In the SDSL Line Profile Table window, locate the table row that contains the SDSL line
profile you want to delete.
Click and if necessary to view the entire table. displays the beginning of the
table. displays the next page of the table.
2 Select the Delete check box next to the row that contains the profile you want to delete. To
select the Delete check box for all rows (except the default profile, which cannot be
deleted), click Check All .
If you decide not to delete a selected row, clear the Delete check box next to the row. Click
Clear All to clear the Delete check box for all rows.
3 Click Delete Checked Row(s) to delete the profiles.
A confirmation dialog displays.
4 Click OK to delete the selected table rows, otherwise click Cancel .
You cannot delete profiles that are assigned to ports.
