Chapter 23: Configuring Frame Relay Interworking
Avidia System Configuration and Management User Manual 469
The Frame Relay Interworking Configuration Table window displays the operating status and a
subset of the frame relay parameters set using the Add Frame Relay Interworking Configuration
window.
Status Box Description
Admin Status The administrative status of the frame channel card
and line card connection: Up (activated) or Down
(deactivated).
Oper. Status The operating status of the frame channel card and line
card connection (Up or Down).
Channel Slot The frame card slot and port number in the format
slot.port. For example, slot 4 port 1 would be 4.1.
Line Card The type of line card.
Line Slot The line card slot and port number in the format
slot.port.
Line VPI The fr VPI of the fr VCC between the frame channel
card and the line card.
Line VCI The fr VCI of the fr VCC between the frame channel
card and the line card.
Data Link LMI Type The Local Management Interface type (None, Rev-1,
Annex A, or Annex D).
Circuit DLCI The Data Link Connection Identifier (range: 16-991).
Interworking The frame relay interworking standard (FRF.5 or
FRF.8)
Traffic Type The traffic class (UBR, CBR, rt-VBR, or nrt-VBR).
