Chapter 23: Configuring Frame Relay Interworking
Avidia System Configuration and Management User Manual
477
6
If
Interworking FRF.8
displays, you can do the following:
a
To modify the LP Mode, in the
LP Mode
box select the desired setting (
1
or
2
).
b
To modify the LP Value. in the
LP Value
box select the value used when
LP Mode
is set
to
2
(
0
or
1
).
c
To modify the CI Mode, in the
CI Mode
box select the desired setting (
1
or
2
).
d
To modify the DE Mode, in the
DE Mode
box select the desired setting (
1
or
2
).
e
To modify the DE Value, in the
DE Value
box select the value used when
DE Mode
is set
to
2
(
0
or
1
).
7
Do one of the following:
•
To save the modified frame relay configuration click
Set
, then in the confirmation
dialog click
Back
to return to the
Frame Relay Interworking Configuration Table
window.
•
To cancel modifying the configuration and to return to the
Frame Relay Interworking
Configuration Table
window, click
Cancel
.
