Configuring SDSL Frame Alarm Profiles
114 Avidia System Configuration and Management User Manual
C
ONFIGURING
SDSL F
RAME
A
LARM
P
ROFILES
SDSL frame alarm profiles determine the conditions that generate SNMP traps. When the
configured thresholds are met or exceeded, the SNMP agent sends a trap to the configured trap
receiver(s). Only one trap is sent for each 15-minute data collection period. SDSL frame port
configuration requires assigning an alarm profile, therefore you must configure the desired
alarm profile prior to configuring the SDSL frame port. A default profile exists with an index
of 1. You cannot delete the default profile.
You configure SDSL frame alarm profiles from the ::alarm=> prompt. From the ::root=>
prompt, type the following command then press to display the ::alarm=> prompt.
configuration sdsl frame profile alarm
Adding SDSL Frame Alarm Profiles
From the ::alarm=> prompt, type the new command in the following format then press
to create a new SDSL frame alarm profile. The profile is automatically assigned the next
available index number in the SDSL frame alarm profile table.
new
Parameters
Loss of Sync Word alarm setting. A Loss of Sync Word alarm occurs when one of the
SDSL frame loops is out of sync. Type
enable or disable .
The margin threshold value, in decibels. When the margin falls below the specified
threshold, the margin alarm is activated. A typical margin threshold value is 6.
The margin alarm setting. Type enable or disable .
The errored seconds threshold. When the number of errored seconds in the current
15-minute data collection interval exceeds the specified threshold, the errored seconds
alarm is activated. Errored seconds are seconds during which errors occur that prevent the
payload from being corrected. A typical errored second threshold value is 17.
ENTER
ENTER
