Configuring Bridging and Routing Sessions
490 Avidia System Configuration and Management User Manual
10 If you selected Routing in Step 8 , do the following:
a In the RIP Send box, select the desired type of RIP packets to be sent ( Do Not Send RIP
packets, RIP Version1 , RIP 1 Compatible (RIP2-type packets that are compatible with
RIP 1), or RIP Version2 ).
The RIP type is determined by the RIP version used by the other routers in the network.
b In the RIP Receive box, select the desired type of RIP packets to be received ( RIP1 , RIP2 ,
RIP 1 or RIP2 , or Do Not Receive RIP packets).
c Click Browse to display the Router Group Table window.
d Click to select the router group that contains the IP address and subnet mask you
want to assign to this session (see “Configuring Router Groups” on page 493 for
information on Router Groups). The Router Group Table window closes and the selected
IP address and subnet masks are assigned to the session.
11 Do one of the following:
• To activate the settings and close the Add Session Entry window, click Set , then in the
confirmation dialog click Back .
• To cancel the settings and close the Add Session Entry window, click Cancel .
