Monitoring System IP Statistics
312 Avidia System Configuration and Management User Manual
Information Description
Datagrams Received The number of IP datagrams received by the system.
Errored Header The number of IP datagrams received by the system that contained
errored headers.
Errored IP Addresses The number of IP datagrams received by the system that contained an
error in the destination IP address.
Datagrams Forwarded The number of IP datagrams forwarded by the system.
Unknown Protocol The number of IP datagrams received by the system that used a
protocol the system does not recognize or support.
Input Datagrams
Discarded The number of received IP datagrams discarded by the system.
Datagrams Delivered The number of IP datagrams successfully delivered to the system.
Datagrams Transmitted The number of datagrams generated by the router (e.g., a ping
request).
Output Datagram
Discards The number of transmitted IP datagrams discarded by the system.
Output Datagram
Discards (No Route) The number of packets for which the system did not have an entry in
the Routing Table and which were routed using the default route.
Reassembly Timeout The maximum number of seconds that fragments are held for
reassembly. This value is always 60.
Fragments Needed
Reassembly The number of fragments that have needed reassembly.
Datagrams Reassembled The number of IP datagrams reassembled successfully.
Datagram Reassembly
Failures The number of IP datagrams that were unable to be reassembled.
Datagrams Fragmented The number of IP datagrams that were fragmented successfully.
Datagram Fragmentation
Failures The number of IP datagrams that were unable to be fragmented
successfully.
Datagram Fragments
Generated The number of IP datagram fragments produced by the system.
