Chapter 22: Configuring ATM Virtual Circuits
Avidia System Configuration and Management User Manual
435
2
In the
Admin Status
box, select the administrative status for the PVPC (
Up
or
Down)
.
Up
activates the PVPC.
Down
deactivates the PVPC.
3
In the
Channel Slot
box, select the channel-side card slot number you want to use for
this PVPC.
4
In the
Channel Port
box, select the channel-side card port number you want to use for
this PVPC.
5
In the
Channel VPI
box, type the subscriber-side VPI for this PVPC.
See the table on
for a summary of the supported VPI ranges for each card.
6
In the
Line Slot
box, select the slot number of the line-side card you want to use for this
PVPC.
7
In the
Line Port
box, select the line-side card port number you want to use for this PVPC.
8
In the
Line VPI
box, type a network-side VPI for this PVPC.
See the table on
for a summary of the supported VPI ranges for each card.
9
If you want to create a backup PVPC for the primary PVPC, in the
Line
box select
Backup
.
Then, do the following:
a
In the
Backup Slot
box, select the slot number for the secondary line-side card you want
to use for this backup PVPC.
b
In the
Backup Port
box, select the port number for the secondary line-side card you want
to use for this backup PVPC.
c
In the
Backup VPI
box, type a network-side VPI for this backup PVPC. The VPI
value can be either the same value as the primary PVPC or a different value for the
backup PVPC.
See the table on
for a summary of the supported VPI ranges for each card.
10
In the
Traffic Profile
box, click
Browse
to display the
ATM Traffic Descriptor Configuration Table
window.
