Surface Scan Statistics
[Survey] [Surface Scan] [Next >]
The Surface Scan Statistics screen displays details about the surface that was just defined.
Store Pts: This box should be checked to store the points that are shot during the surface scan. Enter the starting point
number in the corresponding field.
[Back]: Returns to the previous screen .
[Go >]: Opens the Surface Scan Results screen
Surface Scan Results
[Survey] [Surface Scan] [Next >] [Go >]
The Surface Scan Results screen contains two cards that detail the progress of the surface scan. The Map card shows
the points that were shot in green, points that have not yet been shot in gray and rejected points in red.
[Stop] (Results card): Will stop the surface scan.
[> X,Y View] / [> X,Z View] (Map card): Changes the orientation of the current view.
Video Scan
[Survey] [Video Scan]
This feature is only available when using a supported total station with a USB or supported radio connection, and only
on data collectors running Windows Mobile 5.
The Video Scan routine will quickly take several measurements within a predefined area (scan frame). The data is
stored to a *.tsf Point Cloud file, which, along with the raw data file, can be read by Trimble RealWorks software to
digitally model the surface. Full 360° 3D surfaces can be modeled with RealWorks for areas that are scanned from
three different occupy points around the area. RealWorks is also able to integrate any photos taken of the area with the
scanned data.
Polygon Framing / Rectangular Framing: This button toggles between two sets of buttons displayed on the
left side of the screen. When is displayed, a scan frame is defined by tapping three or more points on the screen in
sequence around the scan frame to create a polygon with three or more sides. When is displayed, a rectangular
scan frame is defined by tapping two diagonal corners.
Hatching Tool: Fills an existing scan frame with parallel lines to make it stand out visually.
Clear Scan Frame Data: Clears any scan frame data from the screen.
/ Scan Frame Toggle: Inverts the horizontal limits of an existing rectangular scan frame. This tool can be
used to quickly define a 360° scan frame for taking panoramic photos by first creating a rectangular scan frame with
