LogicPro User’s Guide Chapter 6: Variables
Doc.# 28002-00 Rev 3.00 Watlow Anafaze 69
4. Variable Type Short, Input or Output, Size and Driver
Name are case sensitive.
5. Initial Values: See “Naming Conventions” on page 49.
Example of an Import/Export File
[RESOURCE:PPC_2000]
[]
Alarm_Status1,INT,0,,,I,W,Database,95.1
Analog_In1_1,INT,0,,,I,W,Analog_In_202x,1.1
Analog_Out11_1,INT,0,,,Q,W,Encoder_Analog_2030,11.1
Control_Mode_I1,INT,0,,,I,W,Database,1.1
Control_Mode_O1,INT,0,,,Q,W,Database,1.48
Dig_In1,BOOL,0,,,I,X,Processor_2010,0.1
Dig_Out25,BOOL,0,,,Q,X,Processor_2010,0.25
Encoder_In11_1,INT,0,,,I,W,Encoder_Analog_2030,11.1
Heat_Output_I1,INT,0,,,I,W,Database,36.1
Heat_Output_O1,INT,0,,,Q,W,Database,36.1
Setpoint_I1,INT,0,,,I,W,Database,95.1
Setpoint_O1,INT,0,,,Q,W,Database,95.1
[END]
Table 6.2 Selected Explanations of the Ex-
ample Import/Export File
Code Explanation
[RESOURCE:PPC_2000]
The first line indicates that
these are RESOURCE type
Variable and the name of
the RESOURCE is
PPC_2000.
[ ]
The second line is empty
except for the opening
bracket ( [ ) and closing
bracket ( ] ).
Alarm_Status1,INT,0,,
,I,W,Database,95.1
Variable Name, Variable
Type Short, Retentive Flag,
Initial Value, Comment,
Input or Output, IO Size,
Driver Name, IO Address.
Analog_In1_1,INT,0,,,
I,W,Analog_In_202x,1.
1
Variable Name, Variable
Type Short, Retentive Flag,
Initial Value, Comment,
Input or Output, IO Size,
Driver Name, IO Address.
