Chapter 11: User Defined Function Blocks LogicPro User’s Guide
178 Watlow Anafaze Doc.# 28002-00 Rev 3.00
3. Select User Defined Function Block to close the
header and C files of the selected UDFB.
4. Select the UDFB you want to close. You will be
prompted to save any files that have changed.
5. Click [OK] .
Saving UDFB Files
You can save the UDFB header and C files by selecting Save
from the File menu.
Deleting UDFBs
To delete UDFBs:
1. Select File .
2. Select Delete .
3. Select User Defined Function Block to remove the
files for one or more UDFBs. The Delete User
Defined Function Block dialog box appears, as
shown in Figure 11.7.
4. Select the UDFBs you want to delete.
5. Click [OK] to delete the UDFBs
–or–
[Cancel] to abort the action.
Figure 11.7 Delete User Defined Function
Block Dialog Box
