LogicPro User’s Guide Chapter 2: LogicPro Workplace
Doc.# 28002-00 Rev 3.00 Watlow Anafaze 11
View Menu
This menu allows you to customize the appearance of your
workspace. See Table 2.3 for a detailed listing of each menu
item. An enabled selection is easily identified by a checkmark
to the left of a menu item.
Table 2.3 The View Menu
Tools Menu
This menu contains the tools associated with your choice of
programming language. Choose your programming language
in the first menu item. The other available options are driven
by this choice. See Table 2.4 on page 12 for a detailed listing
of the languages and their options.
Menu Option Description
Zoom…
Changes the magnification for the
active window from 10% - 200%. This
option allows you to view as little or as
much of the active window as you
desire.
Zoom settings are only kept while the
window is open. The next time you
open the window the zoom setting
reverts to the default 100% setting.
Repaint
Redraws the active window and dis-
plays the latest changes recorded in
the system.
Grid
Superimposes a grid pattern over the
workspace as an aid to placing items.
Comments
Allows you to toggle ladder rung com-
ments on and off in the active window.
Monitor Program
Allows you to see the real-time status
of the downloaded PLC program.
Monitor On/Off
Allows you to selectively suspend
real-time monitoring messages to a
PLC program on a window by window
basis.
Configuration
Displays a partial IEC 1131-3 configu-
ration descriptor.
