Using Standard Windows Features
LogicPro provides standard Windows features. If you are
already familiar with Windows, the
Select, Cut, Copy and
Paste tasks are familiar.
You can access the Cut, Copy or Paste commands from
Edit on the Menu Bar, or from the buttons on the Standard
toolbar. You can also access these features using the short cut
keys (, , and respectively).
SFC Actions
Cut and copy SFC actions in the following manner:
1. Click the action with the Selector tool. This creates
handles around the action.
2. Use the short cut keys or menu options to either Cut or
Copy the action onto the clipboard.
3. Paste the action into other SFC diagrams using either
the Edit menu or short cut keys.
If you paste the action on to the same level of SFC, you must
change the action name. The editor will prompt you for this
change when required.
Pasted items appear at the bottom of the list. If you need the
pasted section to appear higher-up in your diagram you must
cut everything above it and paste it below.
Ladder Rungs
Edit Ladder rungs in the following manner:
1. Click the rung number to the left of the ladder rung with
the Selector tool. Multiple rungs can be simultaneously
selected, or lassoed.
2. Use the short cut keys or menu options to either Cut or
Copy the selection onto the clipboard.
3. Paste the contents of the clipboard into any ladder dia-
gram using either the Edit menu or short cut keys.
Programming
Language
Items that can be Cut, Copied
or Pasted
SFC Actions
Ladder Diagram Ladder Rungs
UDFB Text
