Chapter 16: Cross-Referencing LogicPro User’s Guide
250 Watlow Anafaze Doc.# 28002-00 Rev 3.00
4. You can minimize and move the Cross Reference
dialog box so that you can view and edit portions of the
Program. If you change the Program or Variables, the
Cross Reference dialog box data is not updated until
you close and then reopen the dialog box.
5. Click [Print] to print the on-line cross-reference listing.
6. Click [OK] to close the dialog box.
Figure 16.1 The Cross-Reference Pointer
Ladder On-line Cross-Reference
To perform a Ladder On-line cross-reference, while in a
Ladder window:
1. Select the Tools menu.
2. Select Cross Reference
- or -
Click the
[Cross Reference] button on the toolbar.
The standard pointer changes into a modified pointer, as
shown in Figure 16.1.
3. Click on a Ladder element, Function Block, or Rung for
which you want to view a cross-reference. The
Cross
Reference dialog box appears. This dialog lists all the
Variables present for that element, Function Block, or
Rung and its location in the Program.
4. If you click outside all elements, the Cross Reference
dialog box appears and lists all the Variables present for
the entire ladder window and their location in the
Program.
5. You can minimize and move the Cross Reference
dialog box so that you can view and edit portions of the
Program. If you change the Program or Variables, the
Cross Reference dialog box data is not updated until
you close and then reopen the dialog box.
6. Click [Print] to print the on-line cross-reference listing.
7. Click [OK] to close the dialog box.
XRF
