80 Introduction
2.2 V
isual displa
y unit and k
e
yboar
d Set the screen layout
You select the screen layout yourself: In the PROGRAMMING AND
EDITING mode of operation, for example, you can have the TNC show
program blocks in the left window while the right window displays
programming graphics. You could also display the program structure
in the right window instead, or display only program blocks in one large
window. The available screen windows depend on the selected
operating mode.
To change the screen layout:
Press the screen layout key: The soft-key row shows
the available layout options (see "Operating modes",
page 82)
Select the desired screen layout
