Teach-In
Actual positions can be transferred directly into the NC program
Program verification graphics
Display modes
Graphic simulation before program run, even while another program is being run
Plan view / projection in 3 planes / 3-D view
Magnification of details
Programming graphics
In the Programming and Editing mode, the contour of the NC blocks is drawn on
screen while they are being entered (2-D pencil-trace graphics), even while another
program is running
Program Run graphics
Display modes
Graphic simulation of real-time machining in plan view / projection in 3 planes / 3-D
view
Machining time
Calculating the machining time in the Test Run mode of operation
Display of the current machining time in the Program Run operating modes
Contour, returning to
Mid-program startup in any block in the program, returning the tool to the calculated
nominal position to continue machining
Program interruption, contour departure and return
Datum tables
Multiple datum tables
Pallet tables
Tool-oriented or workpiece-oriented execution of pallet tables with any number of
entries for selection of pallets, part programs and datums
Touch probe cycles
Calibrating the touch probe
Compensation of workpiece misalignment, manual or automatic
Datum setting, manual or automatic
Automatically measuring workpieces
Cycles for automatic tool measurement
Cycles for automatic kinematics measurement
Specifications
Components
Main computer: MC 74xx or MC 75xx, MC 6441, MC 65xx oder MC 66xx
Controller unit: CC 6106, 6108 or 6110
Remote keypad
15.1-inch or 19-inch TFT color flat-panel display with soft keys
IPC 6341 Industrial PC with Windows 7 (option)
Program memory
At least 21 GB, up to 130 GB depending on main computer
Input resolution and display
step
As fine as 0.1 µm for linear axes
Up to 0.0001° for rotary axes
Input range
Maximum 99 999.999 mm (3937 inches) or 99 999.999°
