166

Programming: Programming Aids

4.5 3-D line gr

aphics (FCL2 function)

Highlighting NC blocks in the graphics

Shift the soft-key row

To highlight the NC block selected in the left window

in the 3-D line graphics in the right window, set the

MARK THIS ELEMENT OFF / ON soft key to ON.

To not highlight the NC block selected in the left

window in the 3-D line graphics in the right window,

set the MARK THIS ELEMENT OFF / ON soft key to

OFF.

Block number display ON/OFF

Shift the soft-key row

Show block numbers: Set the SHOW OMIT BLOCK

NR. soft key to SHOW

Hide block numbers: Set the SHOW OMIT BLOCK

NR. soft key to OMIT

Erasing the graphic

Shift the soft-key row

Erase graphic: Press CLEAR GRAPHICS soft key
