HEIDENHAIN iTNC 530 731
1
8
.3 T
ec
hnical inf
o
rm
ation
Software option 1
Rotary table machining  Programming of cylindrical contours as if in two axes
 Feed rate in distance per minute
Coordinate transformation  Tilting the working plane
Interpolation  Circular in 3 axes with tilted working plane
Software option 2
3-D machining  3-D tool compensation through surface normal vectors
 Using the electronic handwheel to change the angle of the swivel head during program
run without affecting the position of the tool point. (TCPM = Tool Center Point
Management)
 Keeping the tool normal to the contour
 Tool radius compensation perpendicular to traversing and tool direction
 Spline interpolation
Interpolation  Linear in 5 axes (subject to export permit)
DXF converter software option
Extracting contour programs
and machining positions from
DXF data and from
conversational programs  Supported DXF format: AC1009 (AutoCAD R12)
 For plain-language and smarT.NC
 Simple and convenient specification of reference points
 Select graphical features of contour sections from conversational programs
Dynamic Collision Monitoring (DCM) software option
Collision monitoring in all
machine operating modes  The machine manufacturer defines objects to be monitored
 Fixture monitoring is also possible
 Three warning levels in manual operation
 Program interrupt during automatic operation
 Includes monitoring of 5-axis movements
 Test run to check for possible collisions before machining
Global Program Settings software option
Function for superimposing
coordinate transformations in
the Program Run modes  Swapping axes
 Superimposed datum shift
 Superimposed mirroring
 Axis locking
 Handwheel superimposition
 Superimposed basic rotation and datum-based rotation
 Feed rate factor
