18.3 Technical information
Explanation of symbols
Default
Axis option
Software option 1
Software option 2
User functions
Short description
Basic version: 3 axes plus spindle
16 additional axes or 15 additional axes plus 2nd spindle
Digital current and shaft speed control
Program entry
HEIDENHAIN conversational format, with smarT.NC and as per ISO
Position data
Nominal positions for lines and arcs in Cartesian coordinates or polar coordinates
Incremental or absolute dimensions
Display and entry in mm or inches
Display of the handwheel path during machining with handwheel superimpositioning
Tool Compensation
Tool radius in the working plane and tool length
Radius compensated contour look ahead for up to 99 blocks (M120)
Three-dimensional tool-radius compensation for subsequent changing of tool data
without having to recalculate the program
Tool tables
Multiple tool tables with up to 30 000 tools
Cutting-data tables
Cutting data tables for automatic calculation of spindle speeds and feed rates from tool-
specific data (cutting speed, feed per tooth)
Constant contour speed
With respect to the path of the tool center
With respect to the cutting edge
Parallel operation
Creating a program with graphical support while another program is being run
3-D machining (software
option 2)
3-D tool compensation through surface normal vectors
Using the electronic handwheel to change the angle of the swivel head during program
run without affecting the position of the tool point. (TCPM = Tool Center Point
Management)
Keeping the tool normal to the contour
Tool radius compensation perpendicular to traversing and tool direction
Spline interpolation
Rotary table machining
(software option 1)
Programming of cylindrical contours as if in two axes
Feed rate in distance per minute
