New functions in v
e
rsion 60642x
-02
HEIDENHAIN iTNC 530 17
 New Cycle 225 ENGRAVING (see User’s Manual for Cycle
Programming)
 New Cycle 276 CONTOUR TRAIN (see User’s Manual for Cycle
Programming)
 New Cycle 290 INTERPOLATION TURNING (software option, see
User’s Manual for Cycle Programming)
 In the thread milling cycles 26x a separate feed rate is now available
for tangential approach to the thread (see User’s Manual for Cycle
Programming)
 The following improvements were made to the KinematicsOpt
cycles (see User’s Manual for Conversational Programming):
 Newer, faster optimization algorithm
 It is no longer necessary to run a separate measurement series for
position optimization after angle optimization
 Return of the offset errors (change of machine datum) to the
parameters Q147-149
 More plane measuring points for ball measurement
 Rotary axes that are not configured are ignored by the TNC when
executing the cycle
