9.9 Entering formulas directly
Entering formulas
You can enter mathematical formulas that include several operations
directly into the part program by soft key.
Press the FORMULA soft key to call the mathematical functions. The
TNC displays the following soft keys in several soft-key rows:
Mathematical function Soft key
Addition
Example: Q10 = Q1 + Q5
Subtraction
Example: Q25 = Q7 – Q108
Multiplication
Example: Q12 = 5 * Q5
Division
Example: Q25 = Q1 / Q2
Opening parenthesis
Example: Q12 = Q1 * (Q2 + Q3)
Closing parenthesis
Example: Q12 = Q1 * (Q2 + Q3)
Square of a value
Example: Q15 = SQ 5
Square root
Example: Q22 = SQRT 25
Sine of an angle
Example: Q44 = SIN 45
Cosine of an angle
Example: Q45 = COS 45
Tangent of an angle
Example: Q46 = TAN 45
Arc sine
Inverse of the sine. Determines the angle from the
ratio of the side opposite the angle and the
hypotenuse
Example: Q10 = ASIN 0.75
Arc cosine
Inverse of the cosine. Determines the angle from the
ratio of the side adjacent to the angle and the
hypotenuse
Example: Q11 = ACOS Q40
