716 Tables and Overviews
1
8
.1 Gener
a
l user par
a
met
e
rs
Configuring tool
pocket table (to omit
from the table: enter 0);
Column number in the
pocket table for MP7267.0
Tool number – T: 0 to 20
MP7267.1
Special tool – ST: 0 to 20
MP7267.2
Fixed pocket – F: 0 to 20
MP7267.3
Pocket locked – L: 0 to 20
MP7267.4
PLC status – PLC: 0 to 20
MP7267.5
Tool name from tool table – TNAME: 0 to 20
MP7267.6
Comment from tool table – DOC: 0 to 20
MP7267.7
Tool type – PTYP: 0 to 20
MP7267.8
Value for PLC – P1: 0 to 20
MP7267.9
Value for PLC – P2: 0 to 20
MP7267.10
Value for PLC – P3: 0 to 20
MP7267.11
Value for PLC – P4: 0 to 20
MP7267.12
Value for PLC – P5: 0 to 20
MP7267.13
Reserved pocket – RSV: 0 to 20
MP7267.14
Pocket above locked – LOCKED_ABOVE: 0 to 20
MP7267.15
Pocket below locked – LOCKED_BELOW: 0 to 20
MP7267.16
Pocket at left locked – LOCKED_LEFT: 0 to 20
MP7267.17
Pocket at right locked – LOCKED_RIGHT: 0 to 20
MP7267.18
S1 value for PLC – P6: 0 to 20
MP7267.19
S2 value for PLC – P7: 0 to 20
TNC displays, TNC editor
