416 Programming: Special Functions
1
1
.2 Dynamic Collision Monit
o
ri
ng (sof
tw
ar
e option)
You can switch between the various views via soft key:
Mouse operation: (see "Graphic depiction of the protected space
(FCL4 function)" on page 414)
Function Soft key
Switch between wire-frame and solid-object
view
Switch between solid and transparent view
Display/hide the coordinate systems that result
from transformations in the kinematics
description
Functions for rotating in the X and Z axes, and
magnifying/reducing
